A-5000 - ЦИФРОВОЙ МИКШЕРНЫЙ УСИЛИТЕЛЬ

Питание

100 - 240 V AC, 50/60 Hz

Номинальная мощность Вт

60Вт

120Вт

Ток потребления

106 W(rated output), 20 W(based on cULus standards) Max. 2 A

207 W (rated output), 39 W(based on cULus standards) Max. 3 A

Частотный диапазон

50 Hz - 20 kHz (1/8 rated output)

Искажения

1 % or less (1 kHz, rated output)

Входы

INPUT 1, 2: MIC -60 dB*, LINE -20 dB*, MIC/LINE selectable
2.2k ohms, electronically-balanced, removable terminal block (5 pins)
INPUT 3, 4: LINE -20 dB*, 10k ohms, unbalanced, RCA pin jack

Выходы

SPEAKER: 4 ohms, 70 V (83 ohms), 100 V (170 ohms)
removable terminal block (5 pins)

Speaker: 4 ohms, 70 V (42 ohms) , 100 V (83 ohms)
removable terminal block (5 pins)

Соотношение сигнал/шум

MIC 1, 2: 50 dB or more, LINE 1 - 4: 70 dB or more (A-weighted)

Функционал

Equalizer: 5 points settable on each input (High-pass filter x 1, Parametric equalizer x 4)
High-pass filter: 20 Hz - 20 kHz, 6 dB/oct
Parametric equalizer: 20 Hz - 20 kHz, +/-15 dB, Q: 0.267 - 69.249
FBS: ON/OFF settable on inputs 1 and 2 (OFF by defalt)
Compressor: ON/OFF settable on inputs 1 and 2 (OFF by defalt)
Threshold, Ratio, Attack time, Release time, and Gain are settable independently on each input.
Mute: MANUAL/AUTO/OFF settable on each input (MANUAL by default)
Reduction level, Hold time and Fade-in time are settable independently on each input. Trigger threshold is settable indepen-
dently on input 1. (AUTO)
Equalizer: 10 points settable on output. (Through, Low-pass filter, Parametric equalizer, High-pass filter)
Low-pass filter: 20 Hz - 20 kHz, 6 dB/oct, 12 dB/oct
Parametric equalizer: 20 Hz - 20 kHz, +/-15 dB, Q: 0.267 - 69.249
High-pass filter: 20 Hz - 20 kHz, 6 dB/oct, 12 dB/oct
Speaker parametric equalizer: 5 points settable on each output
20Hz - 20 kHz, +/-15 dB, Q: 0.267 - 69.249

Сетевой вход/вывод

100 BASE-TX

Размер

210 (W) X 52.5 (H) X 375 (D) mm (8.27" x 2.07" x 14.76")

Вес

3.6 kg (7.94 lbs.)

3.9 kg (8.6 lbs.)
